Model | XY-4300 | XY-5230 | XY-6120 | ||
Working range (mm) | X400*Y1/300*Y2/300*Z120 | X500*Y1/300*Y2/300*Z120 | X600*Y1/400*Y2/400*Z120 | ||
Maximum load | X/Y：10kg；Z：5KG | ||||
Moving speed | X/Y：≤500mm/s；Z：≤200mm/s | ||||
Motion accuracy | ±0.03mm | ||||
Motor system | Stepper motor + linear guide rail drive | ||||
Dispensing method | Syringe / high precision dispensing valve outlet | ||||
Control system | Motion control card | ||||
Panel control | Position adjustment, micro advance, program selection | ||||
Control mode | Point to point, line to arc compensation | ||||
Programming mode | Hand held teaching pendant | ||||
Delimitable graph | Line, garden, arc; Continuous scribing; Drop, glue | ||||
Motion interpolation function | Any 3D route | ||||
Input power | AC220V 50-60Hz | ||||
Operating temperature | 10-40℃ | ||||
Operating humidity | 20-90% no condensation | ||||
Dimension W*D*H (mm) | 560*500*590 | 705*590*600 | 790*630*600 | ||
Weight | Around60kg | Around57kg | Around80kg | ||
