Models | XY-200 | XY-1230 | XY-1240 | XY-1250 |
Working range (mm) | X200*Y200*Z120 | X300*Y300*Z120 | X400*Y400*Z120 | X500*Y500*Z120 |
Maximum load | X/Y：8kg；Z：5KG | |||
Moving speed | X/Y：≤500mm/s；Z：≤200mm/s | |||
Motion accuracy | ±0.03mm | |||
Motor system | Stepper motor + linear guide rail drive | |||
Dispensing method | Syringe / high precision dispensing valve outlet | |||
Control system | Motion control card | |||
Panel control | Position adjustment, micro advance, program selection | |||
Control mode | Point to point, line to arc compensation | |||
Programming mode | Hand held teaching pendant | |||
Delimitable graph | Line, garden, arc; Continuous scribing; Drop, glue | |||
Motion interpolation function | Any 3D route | |||
Input power | AC220V 50-60Hz | |||
Operating temperature | 10-40℃ | |||
Operating humidity | 20-90% no condensation | |||
DimensionW*D*H (mm) | 360*460*480 | 485*545*595 | 580*630*590 | 660*700*650 |
Weight | Around40kg | Around55kg | Around65kg | Around75kg |
